转换型（P系列）

产品信息

Crystal水晶系列特点：一体化散热设计，丰富功能，内部无线缆设计，可灵活连接显示屏，变身为功能强大的工业平板电脑。

产品型号	CPU	I/O	Expansion
P2102E	Intel® Core™ i5-8365UE Intel® Core™ i3-8145UE	1x VGA, 1x DisplayPort, 2x GbE LAN, 5x USB , 4x COM, 16x DI	2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN) 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module,1x PCI or 1x PCIe Slo
P2102	Intel® Core™ i5-8365UE Intel® Core™ i3-8145UE	1x VGA, 1x DisplayPort, 2x GbE LAN, 5x USB , 4x COM, 16x DIO	2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN) 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module
P1101	Intel® Atom® x7-E3950 Intel® Pentium® N4200	1x VGA, 1x DisplayPort, 2x GbE LAN, 4x USB 3.0 , 4x COM, 8x DIO	2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
P1001E	Intel® Atom™ E3845 Processor Quad Core, 1.91GHz	1x VGA, 1x DisplayPort, 2x LAN, 4x USB, 2x COM, 8x DIO	1x Mini-PCIe Socket , 2x Universal I/O Brackets
P1001	Intel® Atom™ E3845 Processor Quad Core, 1.91GHz	1x VGA, 1x DisplayPort, 2x LAN, 4x USB, 2x COM, 8x DIO	1x Mini-PCIe socket
P2002E	Intel® 6th Generation Core™ U Series (Skylake)	1x VGA, 1x DVI-D, 2x GbE LAN, 5x USB , 6x COM, 16x DIO	2x Full Size Mini-PCIe Socket, 1x PCI or 1x PCIex4 Socket, and Support CFM (PoE, IGN)
P2002	Intel® 6th Generation Core™ U Series (Skylake)	1x VGA, 1x DVI-D, 2x GbE LAN, 5x USB , 6x COM, 16x DIO	2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
